ホーム > 製品情報 > エクステンダ系製品 > P16S-P16F

    P16S-P16F
M.2 (NGFF) SATA SSDアダプタ

(Socket 2 SATA-based , Key B, Maximum dimension type 22110)




Brief Taiwan 1 Taiwan 2 China
Selection Guide Taiwan 1 Taiwan 2 China
Web-shop


   概要


P16S-P16F is an extender board for M.2 (NGFF) SATA-SSD.
Design the FFC (Flat Flexible Cable) cable for flexible use.
Design type 2242 dimension M.2(NGFF) golden finger for Socket 2 SATA-base Key B/B+M slot.
Can support all dimension of SSD cards: 2230, 2242, 2260, 2280, 22110.
The extender is designed to minimize the signal degradation effects of the extender by proven design techniques.
It’s also a powerful tool for engineers and factory tests.



       機能一覧


  • M.2 Socket 2 SATA-SSD extender board
  • Design the FFC (Flat Flexible Cable) cable for flexible use.



       仕様一覧


  • M.2 Specification Revision 0.9-3
  • Support 2230/2242/2260/2280/22110
    dimension of M.2 SSD Cards.
  • Golden finger base on M.2 Socket2 SATA-base slot, Key B/B+M
  • Support M.2 Socket 2 SATA-SSD, Key B/B+M card type.





  Web-shop


P16S x1
P16F x1
FFC0536P-010A (FFC cable 10cm) x1
FFC0536P-020A (FFC cable 20cm) x1
FFC0536P-030A (FFC cable 30cm) x1
専用平ネジ x2
