Home > Product > 3G/4G Wireless MODEM Adapter > U0901A

   U0901A
3G/4G Wireless MODEM to USB 9P Header







Brief Taiwan 1 Taiwan 2 China
Web-shop


    First Impression


The U0901A adapter is designed for desktop/Embedded system that convert 3G/4G wireless Mini-Card to USB port.
You can insert your USB type minicard such as GSM, HSPA(3.5G), GPS, LTE cards to this adapter then plug to USB port.

Standard SIM card is provided.

        Function


  • USB 9pin connection to desktop or notebook PC
  • Supports USB interface of Mini-Cards such as 2G GSM, GPRS, 3G, CDMA, WLAN, WWLAN, HSPA MODEM, GPS, 4G WiMAX, LTE, and Mini-Card to desktop PC
  • Support SIM card connector.
  • Support U.FL/IPX to SMA pigtail RF cable adapter
  • Support MHF4 to SMA pigtail RF cable adapter
  • (Option) 824-984MHz; 1850-1990MHz SMA Antenna
  • (Option) 800-960MHz; 1710-2170MHz SMA Antenna
  • (Option) 700-960MHz; 1710-2700MHz SMA Antenna
  • (Option) 694-960MHz; 1710-2170MHz SMA Antenna
  • (Option) SMA or RP-SMA to U.Fl/IPX RF Cable
  • (Option) PCB Pad (Protect your desktop)
  • (Option) 3G CDMA / 4G LTE MiniCard
  • (Option) PCIe Standard Height 4 Antenna Hole Bracket (JP0593)
  • (Option) PCIe Low Profile Height 3 Antenna Hole Bracket (JP0735)



        Specifications


  • System Requirements
    USB 2.0 9pin port
    Full / Half -Mini Card dimension
  • Dimension
    90mm X 40mm X 7mm
  • Certifiction
    RoHS
  • Operating Temperature
    0 ~ 70℃




All of Model Where to buy? Special Information
U0901A PCBA V1.0 Web-shop 3G/4G Wireless MODEM to USB 9P Header
U0901A V1.0 Contact Sales 3G/4G Wireless MODEM to USB 9P Header with a Mu709s-3 LTE module.



    Web-shop





U0901A V1.0
Unit price: USD 74.
U0901A PCBA V1.0
(3G/4G Wireless MODEM to USB 9P Header) x1
Y09-U12-030
(USB2.0 9PIN cable 30cm) x1
2.0cm Pillars x1
M3x4 Screw x1
Screw x2




Buy Related Items


U0902A
U0909A
