   U3M2M
M.2 PCIe SSD to USB3.0 Adapter




Brief Taiwan 1 Taiwan 2 China
Dimension Taiwan 1 Taiwan 2 China
Schematic Taiwan 1 Taiwan 2 China
3D Model Taiwan 1 Taiwan 2 China
Compatibility List Taiwan 1 Taiwan 2 China
SSD Adapter Selection Guide Taiwan 1 Taiwan 2 China
Web-shop


    First Impression

U3M2M is M.2 PCIE SSD to USB3.0 adapter design for PCI-SIG M.2 PCIe SSD mobile solution. This adapter is allow to use M.2 PCIE SSD 2242 / 2260 / 2280 module with KeyM or B+M through USB3.0 port on your desktop or laptop.







        Function

  • Allows user to use standard M.2 PCIe SSD to USB3.0 port in the Desktop or Laptop
  • Compatible with 2240, 2260, 2280 (XXYY: XXmm width, YYmm length) dimension size of M.2 PCIE SSD Module with KeyM or KeyB+M.
  • Active LED
  • Support Hi-Speed USB 3.0(5Gbps), PCIe Gen2 5Gb/s  mass storage interface.



        Noteice

  • Support AHCI type PCIe SSD only. No support for NVMe one
    (ex. SM951).









        Dimension & Weight

  • 98.5mm X 37.5mm X 10mm  ; 23.5g (No SSD included)

        System Requirements

  • Windows XP/Vista/7/8/8.1/Server 2008, Linux, Mac iOS

        Certification

  • RoHS

        Operating Temperature

  • 0 ~ 70℃





    Web-shop


U3M2M
Unit price: USD 180.
* Notice: Support AHCI type PCIe SSD only. No support for NVMe one (ex. SM951).
U3M2M
(M.2 PCIe SSD to USB3.0 Adapter) x1
Enclosure color: Silver
Y09-U09-075
(USB 3.0 Type A to USB Micro B Cable 75cm) x1

Flat-Head Screw x2





U3M2M-R
Unit price: USD 180.
* Notice: Support AHCI type PCIe SSD only. No support for NVMe one (ex. SM951).
U3M2M-R
(M.2 PCIe SSD to USB3.0 Adapter) x1
Enclosure color: Red
Y09-U09-075
(USB 3.0 Type A to USB Micro B Cable 75cm) x1

Flat-Head Screw x2





Buy Related Items

SAMSUNG SM951 Series
M.2 PCIe Gen3 SSD
