First Impression
The CS835A is a SD3.0 (UHS-I/SDR-50)/MMC Memory Card Reader working at USB2.0 5pin header port. It supports USB 2.0 high-speed transmission to Secure DigitalTM (SD), SDHC, miniSD, microSD (T-Flash), MultiMediaCardTM (MMC), RS-MMC, MMCmicro and MMCmobile on one Card Reader. It also supports huge density memory cards (up to 2TB), such as SDXC and Memory Stick XC. As a single chip solution for USB 2.0 flash card reader, the CS835A complies with Universal Serial Bus specification rev. 2.0, USB Storage Class specification ver.1.0, and SD/MMC card interface specification.
The CS835A integrates a high speed 8051 microprocessor and a high efficiency hardware engine for the best data transfer performance between USB and flash card interfaces. Use GL835 as the main chip IC.
|
Specifications
- USB specification compliance
- Comply with 480Mbps Universal Serial Bus specification rev. 2.0
- Comply with USB Storage Class specification rev. 1.0 : Standard Device Driver available.
- Integrated USB building blocks
- USB2.0 transceiver macro (PHY), USB controller, Build-in power-on reset (POR)
- Embedded 8051 micro-controller
- Embedded mask ROM and internal SRAM
- Standard Size SD Card Slot: Secure DigitalTM (SD) and MultiMediaCardTM (MMC)
- Support SD specification v1.0 / v1.1 / v2.0/ SDHC (Up to 32GB)
- Support SD specification v3.0 UHS-I: SDR25/SDR50
- Support SDXC (Up to 2TB)
- Provide Over-Current protection mechanism for safety power supply for SD card.
- On-Chip power MOSFETs for supplying flash media card power
- Support Power Saving mode/ Selective suspend mode for better power management.
|
|
Function
- System Requirements
USB 2.0 port
- Dimension
40mm X 40mm X 6mm (available at low profile height system)
- Certifiction
RoHS
- Operating Temperature
0 ~ 70℃
|
|
